Technical Data Sheet

XGE-HY-(A, B)Water-based epoxy antirust primer grey

Water-based Epoxy Anti-rust Primer · Category: Transmission tower

Two-component water-based epoxy anti-rust primer formulated with advanced emulsion technology. Excellent adhesion to blasted steel, outstanding salt spray resistance, and low VOC for environmentally responsible corrosion protection of structural steel and industrial equipment.

Key Features

240-1000 hours salt spray resistance (depending on topcoat system) Excellent adhesion on sand-blasted steel (Sa 2½) Low VOC (< 50 g/L), water-based, low odor Compatible with both water-based and solvent-based topcoats Fast dry-to-recoat, suitable for shop and field application

Typical Applications

Structural steel
Bridges
Industrial machinery
Storage tanks
Pipelines

Technical Specifications

Type
Two-component water-based epoxy
Color
Grey / Red-brown / Custom
Solid content≥ 55%
Mixing ratioA:B = 5:1 by weight (typical)Pot life≥ 2 hours @ 25°C
Dry to touch≤ 1 hour @ 25°C
Recoat time≥ 4 hours, ≤ 7 days
Salt spray≥ 240h (single coat), 1000h+ with topcoat
Adhesion
Grade 0-1 (cross-cut)VOC< 50 g/L
Coverage8-10 m²/kg @ 50μm DFT

Application Notes

Surface preparation: Remove all oil, grease, dirt, and loose rust. Abrasive blast to Sa 2½ (ISO 8501-1) for best results, or power tool clean to St 3 minimum. Apply on dry surface with substrate temperature at least 3°C above dew point.

Mixing: Stir component A thoroughly, then add component B (if app
