Technical Data Sheet

Waterborne metallic topcoat (red)

Water-based Metal Paint · Category: Metal paint

General-purpose water-based paint for metal surfaces. Easy application, good durability, and broad color range for industrial and architectural metalwork.

Key Features

Direct-to-metal application Good corrosion resistance Water-based, low odor, fast drying Wide color and gloss range Suitable for shop and field

Typical Applications

Metal furniture
Fencing
Decorative metalworkHVAC
General metal

Technical Specifications

Type
Water-based acrylic
Color
Custom
Solid content≥ 45%
Dry to touch≤ 30 min @ 25°C
Salt spray≥ 200h
Adhesion
Grade 1VOC< 50 g/L
Coverage8-10 m²/kg @ 30μm DFT

Application Notes

Surface preparation: Remove all oil, grease, dirt, and loose rust. Abrasive blast to Sa 2½ (ISO 8501-1) for best results, or power tool clean to St 3 minimum. Apply on dry surface with substrate temperature at least 3°C above dew point.

Mixing: Stir component A thoroughly, then add component B (if applicable) in the correct ratio. Mix with mechanical stirrer for 3 minutes until uniform. Pot life varies by product, typically 2 hours at 25°C.

Application: Airless spray is recommended for best results. Brush or roller suitable for small areas and touch-up. Apply in even, wet coats to specified DFT. Do not exceed recommended film thickness to avoid sagging.

Storage & Safety

Store in original sealed container between 5-35°C, away from direct sunlight and freezing. She
