Technical Data Sheet

Waterborne insulating paint

Water-based Industrial Coating · Category: Oil tank

Waterborne insulating paint — high-performance water-based industrial coating manufactured by SGTECH Coatings. Designed for demanding industrial applications requiring balanced corrosion protection, environmental compliance, and ease of application.

Key Features

Water-based, low VOC (< 80 g/L) Excellent adhesion and durability 240h+ salt spray resistance Compatible with primer systems Custom colors available

Typical Applications

General steel
Industrial equipment
Structural steel
MachineryOEM

Technical Specifications

Type
Water-based industrial coating
Color
Custom
Solid content≥ 50%DFT30-80μm typical
Salt spray≥ 240h
Adhesion
Grade 0-1VOC< 80 g/L
Coverage8-10 m²/kg @ 40μm DFT

Application Notes

Surface preparation: Remove all oil, grease, dirt, and loose rust. Abrasive blast to Sa 2½ (ISO 8501-1) for best results, or power tool clean to St 3 minimum. Apply on dry surface with substrate temperature at least 3°C above dew point.

Mixing: Stir component A thoroughly, then add component B (if applicable) in the correct ratio. Mix with mechanical stirrer for 3 minutes until uniform. Pot life varies by product, typically 2 hours at 25°C.

Application: Airless spray is recommended for best results. Brush or roller suitable for small areas and touch-up. Apply in even, wet coats to specified DFT. Do not exceed recommended film thickness to avoid sagging.

Stora
